The World's highest railway tunnels
Country Tunnel name Length Height Date of
opening
Notes
China Fenghuoshan 1 338 m 4 905 m Under construction October 19 2002 saw the successful liking up of Fenghuoshan Tunnel, the highest among frozen earth tunnels of the world, marking important progress in the construction of Qinghai - Tibet Railway. Due to the extreme lack of oxygen inside the drilling site, oxygen generation machines had to be installed inside the tunnel so as to provide builders with enough oxygen to keep the drilling process as scheduled.
Argentina ? ? 4 817 m ?
Peru La Galera 1 177 m 4 781 m   Meiggs mountain. Central Line of Peruvian railways



The World's highest road tunnels
Country Tunnel name Length Height Date of
opening
Notes
USA Eisenhower Memorial 2 731 m
2 725 m
3 401 m 21.12.1979
08.03.1973
The main artery for East/West travel through Colorado is I-70, 450 miles of Interstate highway stretching from Utah to Kansas. At the 1/2 way point is the Eisenhower/Johnson Memorial Tunnel, a marvel of engineering which took 11 years to complete. Situated at 11, 112 feet above sea level, it is the highest vehicular tunnel in the world. Its twin 2 lane bores are 1.7 miles long.
Tajikistan Anzob 5000 m 3 372 m 2006 The tunnel will open a permanent road between Khujand, Dushanbe, Kulob, and Khorugh. The construction was stopped during the 1992-1997 civil war in Tajikistan. It was resumed in 1997.
Afghanistan Salang 2 700 m 3 363 m
3 360 m
1964 Reopened for one way traffic 19.01.2002.
World's highest road tunnel until 08.03.1973
Bolivia San Rafael 1 374 m 2 942 m
2 845 m
2004 Cotepata - Santa Barbara road. Work started 06.2001
Austria Tiefenbach 1 729 m 2 822 m
2 672 m
1982 North
South
Austria Hoctor 311 m 2 504 m 03.08.1935 Grossglockner High Alpine Road
